| Model No. | DS360 BK |
| TDP | 310W |
| Tube Length | 400mm |
| Radiator Dimension | 396×120×27mm(L×W×H） |
| Radiator Material | Aluminum |
| Waterblock Dimension | 73x73x66.5mm(L×W×H) |
| Pump Speed | 3200RPM±10% |
| Pump Connector | 3Pin |
| Pump Rated Voltage | 12VDC |
| Pump Rated Current | 0.35-0.42A |
| Pump Rated Power | 4.2-4.9W |
| Intel | LGA115X/1200/1700/1851/20XX |
| AMD | AM4/AM5 |
| Fans Included | 3pcs |
| Fan Dimension | 120x120x25mm |
| Fan Bearing Type | FDB |
| Fan Speed | 500-2200±10%RPM |
| Fan Airflow | 86.73CFM |
| Fan Static Pressure | 3.2mmH2O |
| Fan Rated Voltage | 12VDC |
| Fan Rated Current | 0.2A |
| Fan Rated Power | 2.4W |
| Fan Connector | 4Pin PWM |
| Waterblock Lighting Type | ARGB |
| Waterblock Lighting Connector | 5V 3Pin |
| Waterblock Lighting Rated Current | 0.15-0.55A |
| Waterblock Lighting Rated Power | 0.8-1.4W |
Specification Details Product Type 120 mm PC Case Fan Dimensions 120 × 120 × 25 mm Fan Blade Design 9 aerodynamic blades for improved airflow Airflow ~58.5 CFM per fan Bearing Type Hydraulic (fluid dynamic) bearing Noise Level As low as 6 dB(A) under optimal load Fan Speed Control PWM (automatically adjusts with system temperature) Lighting Addressable RGB (ARGB) lighting with vivid effects Cable Design Daisy-chain PWM + ARGB connectors Anti-Vibration Rubber pads for noise and vibration reduction Build Quality High-durability plastic frame with forward airflow orientation Compatibility Fits standard 120 mm case and radiator mounts Color Black Variants Available in Forward or Reverse airflow versions Use Case Ideal for gaming PCs, custom builds, and radiator setups
Specification Details Product Type 120 mm PC case cooling fan Dimensions 120 × 120 × 25 mm Fan Blade Design 9-blade layout optimized for airflow Airflow Direction Reverse orientation (designed for rear/exhaust airflow) Airflow Rate Approx. 58.5 CFM per fan Bearing Type Fluid dynamic (hydraulic) bearing Noise Level Low-noise operation (quiet at typical speeds) Speed Control PWM adjustable (automatically changes with temperature) Lighting Addressable RGB (ARGB) lighting with vivid effects Cable Setup PWM power + ARGB lighting cables (daisy-chain capable) Anti-Vibration Rubber pads to reduce vibration and noise Frame Color Black Mounting Standard 120 mm mounting for cases and radiators Use Case Exhaust airflow in gaming PCs and custom builds Compatibility All standard ATX/microATX/ITX PC cases with 120 mm fan mounts
Specification Details Net Weight 4 g Thermal Conductivity Higher than MX-4, optimized for modern CPUs and GPUs Thermal Resistance Extremely low, designed for efficient heat transfer Viscosity Around 45,000 poise Density 2.6 g/cm³ Operating Temperature Range −50 °C to +150 °C Volume Resistivity 1.8 × 10¹² Ω·cm Breakdown Voltage 7.5 kV/mm Color / Type Grey, high-viscosity non-curing paste Electrical Conductivity Non-conductive and non-capacitive Compatibility Works with CPUs, GPUs, and console chips Application Small central dot or thin even layer recommended Durability Long-lasting, prevents dry-out and pump-out effect
Specification Details Net Weight 2 g Thermal Conductivity 12.8 W/m·K Thermal Impedance < 0.01 °C·cm²/W Specific Gravity (25 °C) 2.8 g/cm³ Operating Temperature Range −150 °C to +250 °C Color / Type Grey non-curing compound Electrical Conductivity Non-conductive, safe for CPUs and GPUs Compatibility Suitable for CPU and GPU applications Application Thin, even layer for optimal thermal contact Use Case High-performance, overclocked, and gaming systems
